Standard AGV

The Standard AGV Manufacture!

Xi'an Chenghe Industrial Automation Equipment Co., Ltd. specializes in the production of customized logistics system AGV, explosion-proof AGV This series of explosion-proof AGV products have been successfully used in special environments such as aerospace, aviation, weapons, chemical industry, nuclear industry, etc.

Add to Inquiry

AGV Pallet Truck

Vehicle Dimensions: 2200mm(L)*930mm(W)*2200mm(H)Vehicle Weight: 780kgsRated Load: 3000kgsLoad

Add to Inquiry

Heavy load Automated Guided Vehicle

A Heavy-load Automated Guided Vehicle (AGV) is a self-driving robotic transporter specifically

Add to Inquiry

Automated Pallet Truck AGV

Vehicle Dimensions: 2200mm(L)*800mm(W)*2200mm(H)Vehicle Weight: 715kgsRated Load: 2000kgsLoad

Add to Inquiry

Ultra-long Automated Guided Cart

An Ultra - long Automated Guided Cart is a specialized type of Automated Guided Vehicle (AGV). It

Add to Inquiry

Omni-directional Forklift AGV

The omni-directional forklift AGV is engineered to fulfill specific material handling demands. It

Add to Inquiry

Automated Counterbalanced Forklift

Dimensions (mm)： 2330(L)950(W)1920(H) Navigation Type： Magnetic Strip / Color Ribbon / SLAM / GPS

Add to Inquiry

Heavy-Duty AGV Forklift

Dimensions (mm)： 2330(L)950(W)1920(H) Navigation Type： Magnetic Strip / Color Ribbon / SLAM / GPS

Add to Inquiry

Heavy Duty Automatic Transfer Cart

Heavy Duty Automatic Transfer Carts (HDATCs) play a pivotal role in industries requiring the

Add to Inquiry

Customized Automated Guided Cart

A Customized Automated Guided Cart (AGC) is a tailor-made, self-navigating material handling system

Add to Inquiry

Stacker Forklift AGV

Dimensions(mm)：L1618*W960*H1410mm Vehicle Weight: 750kgs Fork Size(mm): L1150*W190*H60mmRated

Add to Inquiry

Automated AGV Pallet Stacker

Dimensions：1631mm(L)*960mm(W)*2180mm(H)(custmizable)Fork

Types of Standard AGV

Why choose us

Expertise

Our expertise extends to AGV Fleet Management and AGV Software, enabling businesses to optimize their operations with real-time monitoring and control. Whether you're in AGV Warehouse logistics, AGV Manufacturing, or industrial automation, Chenghe AGV is your trusted partner for innovative and scalable AGV Automation solutions.

Our Certification

We have obtained the national high-tech enterprise certification, ISO9001 management certification, and is the first AGV manufacturer with explosion-proof certification for the whole vehicle in China. It is also one of the drafting units of national standard of "Safety Code for Automated Guided Vehicles in Explosive Hazardous Environment Applications".

After-sales service

Professional and thoughtful after -sales team, let you worry about us after -sales Intimate service, strong after -sales team support.

Feature	Model	CHC30J
	Rated Load	3000kgs
	Wheelbase	1450mm
	Load Center	600mm
Weight	Weight with Battery	780kgs
Dimensions	Vehicle Dimensions	2200mm(L)800mm(W)2200mm(H)
	Max. Lifting Height	120mm
	Min. Fork Height	85mm
	Fork Size	1200mm(L)180mm(w)54mm(H)
	Min. Turning Radius	1765mm
Performance	Travel Speed (Unloaded/Loaded)	1.4 / 1.1m/s
	Lifting Speed (Unloaded/Loaded)	0.056 / 0.039m/s
	Lowered Speed (Unloaded/Loaded)	0.035 / 0.045m/s
	Grade Ability (Unloaded/Loaded)	10° / 8°
Motor	Battery Type	Lithium Battery / Lead Acid Battery
	Battery Voltage / Capacity	24V- 125Ah / 210Ah
	Charger	24V- 100Ah
Navigation	Navigation Type	Magnetic Strip / Color Ribbon / SLAM / GPS

Advantages of Standard AGV

AGVs increase productivity. They can move materials nonstop at a consistent speed. This constant motion and precise, automated control results in optimized material flow and higher throughput. AGVs eliminate the variability and inefficiencies of human workers. They follow the same paths repeatedly without straying, so you gain plenty of predictability and stability in your operations.

Very safe. AGVs reduce accidents and injuries from material handling equipment by automating the most hazardous and repetitive tasks. AGVs also separate workers from heavy machinery and mobilize loads that would otherwise require manual lifting, pulling, or pushing. Their programmed paths and sensors help avoid collisions with people, infrastructure, and other vehicles.

More flexible than you think. While AGVs follow predetermined paths, they offer flexibility because you can easily reprogram paths and schedules to accommodate changes in your facility or workflow. You can add new paths, change existing ones, or modify vehicle speeds and schedules through the AGV control system. This allows AGVs to adapt to evolving operational needs and support continuous process improvements.

Essential safety features of AGVs

Laser scanners

Mounted on AGVs, laser scanners continuously scan the vehicle's surroundings to detect obstacles, adjusting the AGV's path or stopping it entirely to avoid collisions.

Bumpers

Pressure-sensitive bumpers provide an additional layer of safety, bringing the AGV to an immediate halt upon contact with an object or person.

Emergency stops (E-stops)

E-stop buttons are a critical safety feature allowing human operators to immediately stop an AGV in case of an emergency, ensuring quick response to potential hazards.

Audible and visible warning devices

To enhance awareness among nearby workers, AGVs are often equipped with alarms, lights, or other signals indicating their operational status and movements.

Industries That Use Automated Guided Vehicles

Manufacturing
Manufacturing holds 70% of the AGV market, using them for material, work, and product transport. As a result, AGVs have been driving the creation of smart factories.

Warehouses
Warehouses heavily depend on AGV integration with Warehouse Management Systems (WMS). AGVs are also used for logistics like inventory, order picking, and moving goods. AGVs aid in quality control by analyzing finished products for consistency.

Automotive
In automotive manufacturing, AGVs optimize logistics and production. AGVs like automated forklifts can transport materials and aid assembly line processes.

Agriculture
AGVs navigate in manufacturing and warehouses and are crucial in modern agriculture. They enhance efficiency, precision, and intralogistics in farming. AGVs and AMRs (Automated Mobile Robots) automate tasks like planting, harvesting, and crop maintenance with specialized tools or robotic arms.

FAQ

Q: What are Automated Guided Vehicles (AGVs)?

A: AGVs are driverless vehicles that use navigation systems to transport materials within a facility efficiently and safely.

Q: What are the main advantages of AGVs?

A: AGVs offer increased productivity, reduced labour costs, improved accuracy, and enhanced workplace safety.

Q: What are some challenges associated with using AGVs?

A: AGVs may have high upfront costs, limited flexibility in dynamic environments, and require significant infrastructure adjustments for implementation.

Q: What is the life expectancy of AGV?

A: The life expectancy for AGVs, such as GYPOT's electric Assit Robots, is usually five to seven years, depending on the frequency of maintenance and the operating environment of such machinery.

Q: What speed does AGV move?

A: Speeds can be set between 1.5 and 48.8 metres per minute, truly allowing to you choose the best option for your needs. Continuous Moving Line (CML): if you are looking for more of a traditional assembly line, you may simulate this by setting vehicle speed to as slow as 0.5 metres per minute up to 6.1 metres per minute.

Q: What is the capacity of AGV?

A: Standard AGV tractors have towing capacity of near 1 ton (2200 lbs) but there are supppliers offering payloads of 3 ton, 5 ton and even 20 ton (44.000 lbs).

Q: How can I guarantee an AGV will not tip over when carrying its payload?

A: To ensure this does not happen, acceleration and deceleration parameters must be carefully tuned and then tested heavily with the real vehicle during commissioning (installation). The goal is to define the forward and backward acceleration and deceleration, especially in the case of an emergency stop. On top of that, it is key to limit centrifugal acceleration; in other words limit the vehicle's speed as it turns.

Q: How does an AGV detect cantilevered objects?

A: If the vehicle needs to travel through areas in which there is the possibility of collision with cantilevered objects (such as raised forks), additional detection can be achieved using supplementary 2D laser scanners or 3D cameras.

Q: What type of battery does AGV use?

A: There are two basic battery types available. AGM lead-acid batteries for conventional charging methods and TPPL batteries for the high amperage charging associated with opportunity charging.

Q: What is AGV controller?

A: Our AGV controller is specifically designed for Automated Guided Vehicles (AGV), mobile robots, and forklift AGVs, providing efficient and reliable control solutions.

As one of the leading standard AGV manufacturers and suppliers in China, we warmly welcome you to buy high-grade standard AGV for sale here from our factory. All customized products are with high quality and competitive price.
